AC-DC产品线
AC-DC Isolated SSR Converters- 交直流隔离式副边反响开关电源转换芯片 | ||||||||
Product | Character | Topo-logy | SW Voltage | Standby Power | Output Power | Operating frequency | Package | VCC Operation Voltage |
DK212M | Low Standby-Power Off-line PWM Converters | Flyback | 700V | <60mW | 12W | Variable | DIP-8/ SOP-7 | Self-powered |
DK218M | Low Standby-Power Off-line PWM Converters | Flyback | 650V | <60mW | 18W | Variable | SOP-8 | Self-powered |
DK224M | Low Standby-Power Off-line PWM Converters | Flyback | 650V | <60mW | 24W | Variable | DIP-8 | Self-powered |
DK236M | Low Standby-Power Off-line PWM Converters | Flyback | 650V | <60mW | 36W | Variable | DIP-8 | Self-powered |
DK106 | PWM Converters | Flyback | 700V | <270mW | 6W | 65KHZ | DIP-8/ SOP-8 | Self-powered |
DK1203A | PWM Converters | Flyback | 700V | <270mW | 15W | 65KHZ | DIP-8 | Self-powered |
DK1203B | PWM Converters | Flyback | 700V | <270mW | 12W | 65KHZ | DIP-8 | Self-powered |
DK112A | PWM Converters | Flyback | 700V | <270mW | 15W | 65KHZ | DIP-8 | Self-powered |
DK112B | PWM Converters | Flyback | 700V | <270mW | 12W | 65KHZ | DIP-8 | Self-powered |
DK124 | PWM Converters | Flyback | 700V | <240mW | 18W | 65KHZ | DIP-8 | Self-powered |
DK125 | PWM Converters | Flyback | 700V | <270mW | 24W | 65KHZ | DIP-8 | Self-powered |
AC-DC Isolated PSR Converters- 交直流隔离式原边反响开关电源转换芯片 | ||||||||
Product | Character | SW Voltage | Standby Power | Output Power | CC/CV Precision | Operating frequency | Package | VCC Operation Voltage |
DK903 | Low Standby-Power CC/CV PSR Converters | 850V | <75mW | 3W | ±6%/±3% | Variable | SOP-8 | Self-powered |
DK905 | Low Standby-Power CC/CV PSR Converters | 850V | <75mW | 5W | ±6%/±3% | Variable | SOP-8 | Self-powered |
DK935 | Low Standby-Power CC/CV PSR Converters | 850V | <75mW | 5W | ±6%/±3% | Variable | SOP-7 | Self-powered |
DK906 | Low Standby-Power CC/CV PSR Converters | 700V | <300mW | 6W | ±6%/±3% | Variable | SOP-8 | Self-powered |
DK910 | Low Standby-Power CC/CV PSR Converters | 700V | <75mW | 10W | ±6%/±3% | Variable | SOP-8 | Self-powered |
DK938 | Low Standby-Power CC/CV PSR Converters | 700V | <75mW | 10W | ±6%/±3% | Variable | SOP-7 | Self-powered |
DK912 | Low Standby-Power CC/CV PSR Converters | 700V | <300mW | 12W/15W | ±6%/±3% | Variable | SOP-8/ DIP-8 | Self-powered |
DK913 | Low Standby-Power CC/CV PSR Converters | 700V | <75mW | 12W | ±6%/±3% | Variable | SOP-8 | Self-powered |
AC-DC Non-isolated Converters- 交直流非隔脱离关电源转换芯片 | |||||||
Product | Character | SW Voltage | Standby Power | Output Power | Idlimt | Package | VCC Operation Voltage |
DK501 | CV Buck/Buck-boost Converters | 700V | <100mW | 5V,0.25A/12V,0.25A | 0.48A | DIP-8/ SOP-8 | Self-powered |
DK502 | CV Buck/Buck-boost Converters | 700V | <100mW | 5V,0.3A/12V,0.3A | 0.59A | DIP-8 | Self-powered |
同步整流产品线
Charger IC- 充电器芯片 | ||||||||
Product | Character | Vcc | Supply Current | V_RI | V_RV | Voltage Tolerance | Package | Application |
DK412 | CC/CV Controller | 36V | 500uA | 100mV | 1.20V | ±1% | SOP-8 | Charger/Adapter |
产品特点：
1、全电压输入85V一265V。。。。。
2、内置700V功率管。。。。。
3、专利的自供电手艺，，，，，，，变压器无需外部供电绕组，，，，，，，无需启动电阻（降低制品本钱)。。。。。
4、特有的SLEEP手艺使芯片具有超低的待机功耗。。。。。
5、内置PWM准谐振电路，，，，，，，增添电源转换效率和包管优异的EMC特征。。。。。
6、过温、过流、过压以及输出短路，，，，，，，次级开路，，，，，，，光耦失效�；；；；；；ぁ�。。。。
7、4KV防静电ESD测试。。。。。
